| Response Input / Output | Max. SPL: +20dBu |
| Output Impedance: 50Ω |
| Input Impedance: >10KΩ |
| Analog Audio | Frequency Response: ±0.5dB(20Hz to 20kHz)
|
| SNR:110dB typical (unweighted) |
| CMRR: >40dB(20Hz to 10kHz) |
| Crosstalk: <-100dB |
| Distortion: 0.001%(1kHz@0dBu) |
| Digital Audio | DSP:32 bits (extendable FPU to 40 bits)
|
| Sampling Rate: 96kHz |
| ADC/DC: 24 bits high resolution chip |
| Transmission Delay: 2ms |
| Adjustable Parameters | Master Gain: -12 to 12dB,0.1dB stepping
|
| Channel Gain: -12 to 0dB,0.1dB stepping |
| Delay: parameter |
| EQ Types: oaranter, shelv |
| EQ Gain: -15 to +15dB 0.5dB stepping |
| EQ Bandwidth: 0.009 to 4.8 octaves(Q=0.3 to 20) |
| RMS Limiter | Threshold Value: -10 to +20dBu
|
Compression Ratio: 1:1 to 32:1
|
Starting Time: 5 to 200ms
|
| Release Time: 0.1s to 3s |
| Peak Limiter | Threshold Value: -10 to +20dBu
|
Starting Time: 5 to 200ms
|
| Release Time: 0.1s to 3s |
| General Specification | Power: 90-265VAC(50/60Hz)
|
Dimensions: 483 × 44 × 229 mm
|
Weight: 4.6 kg
|
